High Pressure Washer Structure and Composition: 1. Trademark; 2. Water Inlet; 3. Rear Wheel; 4. Detergent Nozzle; 5. High Pressure Hose; 6. Power Cable; 7. Temperature Control Switch; 8. Power Switch; 9. High Pressure Gun; 10. Shield; 11. Front Wheel; 12. Chassis; Motor and High Pressure Pump Assembly; 14. Heater; 15. Injector and Ignition Electrode Assembly; 16. Chimney; 17. Car Armrest; 18. Fuel Tank; 19. Stock; 20. Fuel Filter; 21. Oil Pump; 22. Fan; The coil is familiar with its structural composition and working principle. High Pressure Washer Troubleshooting : During the use of the washing machine, it's common to encounter malfunctions. When issues occur, it's important to carefully identify the cause based on the specific symptoms. 1. The spray gun does not spray water a) Water inlet filter is clogged. b) Nozzle is blocked. c) The heating coil is clogged; scale removal may be necessary. 2. Unstable water pressure a) Insufficient water supply. b) Air is sucked into the pipeline due to a broken pipe or incorrect installation of the detergent nozzle. c) Nozzle wear. d) Leakage from the high-pressure pump seal. 3. Burner fails to ignite and burn a) Insufficient air intake, resulting in white smoke. b) Clogged fuel filter, fuel pump, or fuel nozzle. c) Solenoid valve damage. d) Ignition electrode position has shifted, causing weak spark. e) High-voltage ignition coil failure. f) Pressure switch damage. The above issues may occur in high-temperature and high-pressure cleaners. Users can identify and resolve these problems themselves. However, if there are serious faults such as water leakage from the pump body or oil leakage from the crankcase, it is recommended to send the unit to a professional maintenance service with full parts and technical expertise to avoid unnecessary financial loss. Shanghai Bayu ( Established in 2007, Shanghai Bayu Industrial Co., Ltd. set up an offline supply system for laboratory instruments and MRO industrial products. In 2009, the company officially launched an online procurement platform. As one of the earliest enterprises in Shanghai engaged in MRO industrial products and laboratory instruments, Shanghai Bayu Industrial Co., Ltd. boasts strong resources, scientific management, quality assurance, comprehensive after-sales service, and a reputation for excellence. Zirconia Ceramics,Zirconia Engineering Components,Zirconia Precision Parts,Zirconia Wear Resistant Parts Yixing Guanming Special Ceramic Technology Co., Ltd , https://www.guanmingceramic.com
