Physical layer
Each version of Ethernet has a maximum cable length limit (that is, the length that does not need to be amplified). Signals within this range can be transmitted normally, and signals beyond this range will not be transmitted. In order to allow the construction of a larger network, multiple cables can be connected with repeaters. A repeater is a physical layer device that can receive, amplify, and retransmit signals in both directions.
On these cables, the transmission of information uses Manchester encoding.
MAC sublayer
Classic Ethernet uses 1-adhere to the CSMA/CD algorithm, that is, when the station has a frame to send, it must listen to the medium, and send it immediately once the medium becomes free. Monitor whether there are conflicts on the channel while they are being sent. If there is a conflict, immediately terminate the transmission, and send a short conflict enhancement signal, and then wait for a random period of time before resending.
The development of Ethernet is very fast, starting to evolve from the typical Ethernet structure of a single long cable. The problems of a single cable, such as finding out the connection-related problems such as broken or loose locations, have driven people to develop a different type of wiring mode. In this mode, each station has a dedicated wire connected to a central hub. The hub simply connects all the connecting wires electrically, like soldering them together. Hubs cannot increase capacity because they are logically equivalent to classic Ethernet with a single cable. As more and more stations join, the share of fixed capacity shared by each station decreases. Eventually, the LAN will be saturated.
There is another way out to handle the ever-increasing load: switched Ethernet. The core of switched Ethernet is a switch, which contains a high-speed backplane that connects all ports. From the outside, switches look like hubs. They are a box, usually with 4-48 ports, and each port has a standard RJ-45 connector for connecting twisted-pair cables. The switch only outputs the frame to the port where the frame wants to go. A machine can be added or deleted by simply plugging in or unplugging the cable, and since the flaky cable or port usually only affects one machine, most errors are easy to find. This configuration mode still has the problem of a shared component failure, that is, the failure of the switch itself: if all stations lose network connectivity, the IT staff knows how to solve this problem: replace the entire switch.
